Hubbell HBLDS100 NM Sloped Disconnect Switch, 100A Unfused

The Hubbell HBLDS100 NM Sloped Disconnect Switch is a rugged, industrial-grade solution for safe motor disconnection. Rated at 100A and 600V AC, this unfused 3-pole switch is built with a corrosion-resistant, UV-stabilized non-metallic enclosure designed to withstand harsh environments. With IP69k and NEMA 4X/12 ratings, it is ideal for industrial, food processing, and washdown applications where hygiene and durability are critical.

Key Features

• Rating: 100A, 600V AC, 3 Pole

• Type: Unfused motor disconnect switch

• Enclosure: Non-metallic sloped top, hygienic design to shed dirt and debris

• Protection: IP69k and NEMA Type 4X/12 for water ingress and corrosion resistance

• Terminals: Screw-type for secure connections

• Handle: Highly visible red handle, lockable in OFF position (OSHA Lockout/Tagout compliant)

• Certifications: cULus, CE, NSF certified, UL 508 / UL 60947-4-1A

• Options: Accepts up to 2 auxiliary contacts (HBLAC1 and/or HBLAC2), or 3 with HBLAC11 combination

• Durability: Corrosion and impact-resistant construction, permanent laser-marked ratings

Compliance & Standards

• Meets NEC Section 430.102(B) motor disconnect requirements

• UL listed as a manual motor controller and suitable as a motor disconnect

Specifications

• Wire Size: 10 AWG

• Color: Gray

• Brand: Hubbell Wiring Device-Kellems

• UPC: 783585763330
